Access and Control
Pushbuttons
EleVisor 200 (EV-200) are pushbuttons that are designed to
meet the diverse needs of access control applications for solid
durability and ease of operation. It features the flexible design
and visual impact as the ideal choice for applications in lift
environment. Moulded in high grade polycarbonate, the button
comes in a wide range of options in shape, finish, legend and
color, allowing clients to choose the button best suited to
location and purpose of use.
The button can be in round or square shape with the pressel in hairline or mirror stainless
steel finish. Floor legend comes with choices of plastic flat, plastic embossed and
stainless steel embossed, and standard braille dots can be embossed onto the surface for
the visually impaired. The illuminations are based on 5mm LED with a wide variety of colors
of choice. Dual color illumination can also be made available. The button has a rugged
design and meets the IP64 standard, which guarantees complete protection against dust
infusion and damage from splashed water.
Specifications
Shape :
Pressel :
Legend :
Braille :
Contact :
Illumunation :
Voltage :
Operation :
Weight :
Protection :
Compliance :
square
round
hairline or mirror stainless steel plate
plastic flat, plastic embossed, stainless steel embossed
standard or nil
1 N/O, 2 N/O, N/C+N/O
red, orange, yellow, green, amber, blue, white
DC 12V, DC 24V
1,000,000 cycle
40g
IP64
EN-81-1/2, EN81-70, EN81-71, EN81-72, EN81-73
*Specification may be subjected to change.
Plastic Flat Legend
Plastic Embossed Legend
with Braille Dots
Stainless Steel Embossed Legend
with Braille Dots
